ZEUS1800-H

Kod EAN: 8051706390157

ZEUS amplifiers always mean reliability and ruggedness. They were born for fixed installations or live applications of low-impedance professional sound systems, and offer RMS powers ranging from 100W to 1000W @ 8ohm per channel. The series consists of 2-c...

viac

690,01 € brutto

(inkl. 23% DPH)
560,98 € netto

Staň sa partnerom
Kúp teraz


ZEUS1800-H

ZEUS amplifiers always mean reliability and ruggedness. They were born for fixed installations or live applications of low-impedance professional sound systems, and offer RMS powers ranging from 100W to 1000W @ 8ohm per channel. The series consists of 2-channel models, three of them in class AB; two in class H. Thus, these are equipment whose technologies are extensively tested and guarantee the highest audio quality. The difference from similar systems depends on the great attention paid to the quality of the components (toroidal transformers, electrolytic capacitors, transistors and others) and to the efficiency of protections and limiter, all while always considering robustness, durability and safety of both internal circuitry and driven speakers.

  • Stereo/parallel/bridged-mono Modes
  • Intelligent Cooling System
  • 2x 19” Rack Unit Chassis Design
  • H-Class traditional and reliable circuitry
  • High-quality transformers and components
  • Thermal, Short Circuit and Signal Protection
  • Soft Start Function

Parametre

Stereo Rated Output Power (THD=0.5%, 1kHz, both channels driven) 2 x 600W @ 8O; 2 x 900W @ 4O
Bridged Output Power 1 x 1800W @ 8O
Input Sensitivity 0.775V / 1.0V / 1.4V
Input Impedance 20KO / 10KO
Frequency Response 20Hz - 20kHz ±0.3dB
Damping Factor > 200
S/N Ratio > 100dB
Amplifier Class H
Power Requirements 230-250Vac – 50/60Hz
Power Consumption (average/max) 1200W / 1820W
Dimension (WxHxD) 483 x 400 x 88 mm (19.0 x 15.7 x 3.5 in)
Výška 2 x 19” Rack Unit
Unit Weight 16.50 kg – 36.4 lbs.
Packing Size (WxHxD) 550 x 480 x 168 mm (21.6 x 18.9 x 6.6 in)
Carton Weight 18.25 kg – 40.2 lbs.

Na stiahnutie

Produktová karta ZEUS1800-H [Eng-Ita] ZEUS AB & H Series-User Manual.pdf
