TWIST-30LED
Kod EAN:
Kompaktná LED otočná hlava
CRC-093v1-0.9
Kod EAN: 1111111111112
The Crystal COB Series is a premium display solution designed for fixed indoor installations requiring exceptional visual clarity and reliability. With an ultra-fine 0.93mm pixel pitch, it delivers stunning detail and sharpness, making it ideal for high-e...
CRC-093v1-0.9
The Crystal COB Series is a premium display solution designed for fixed indoor installations requiring exceptional visual clarity and reliability. With an ultra-fine 0.93mm pixel pitch, it delivers stunning detail and sharpness, making it ideal for high-end corporate environments, control rooms, broadcast studios, and retail spaces. Equipped with Flip-Chip COB (Chip-on-Board) technology, the panel has enhanced performance, durability, and efficiency compared to traditional SMD LEDs. Installation is hassle-free, featuring seamless splicing technology, front service access, and uniform mounting, streamlining setup and maintenance. Its 175° horizontal and vertical viewing angle guarantees superior visibility from any position, providing a truly immersive viewing experience. The panel is sealed with epoxy resin, making it water and dust-resistant, ensuring longevity and stable performance in various indoor environments. Thanks to Black-Seal technology, the panel offers high contrast levels, delivering deep blacks and vibrant colors for exceptional image quality. Pixel-to-pixel calibration ensures precise color accuracy and consistency across the entire display, while a high refresh rate of 7680Hz guarantees smooth, flicker-free visuals, perfect for high-end content playback and live video applications. The Crystal COB Series is the ultimate choice for professionals seeking cutting-edge display technology with refined visuals, high reliability, and effortless integration into modern indoor spaces.
- LED Module pitch 0.93mm for indoor use
- LED Type: Flip-Chip COB
- Hassle-free installation with seamless splicing technology
- 175° x 175° Super viewing angle for an immersive experience
- Water and dust-resistant COB modules
- Black Seal technology for intense contrast and pristine detail
- Pixel-to-Pixel calibration for uniform brightness and colors across multiple displays
- HSP (High Stability Processing) for enhanced stability, clarity, and consistency of visual output
- High refresh rate of 3840Hz
Parametre
| Led Type | Flip-Chip COB |
| Module Dimensions (W x H x D) | 150 x 168.5 x 2mm |
| Module Resolution | 160 x 180 pixel |
| Cabinet Dimensions (W x H x D) | 600 x 337.5 x 27mm |
| Cabinet Resolution | 640 x 360 pixel |
| Cabinet Weight | 4.5 kg |
| N. of modules per panel | 8 |
| Brightness | 800 Nits (average) / 1000 Nits (max) |
| Maintenance | Front |
| Refresh Rate | = 7680Hz |
| Output bit depth | 16 bit (standard) / up to 18 bit |
| Viewing Angle (H/V) | 175°x175° |
| Operating Voltage | 110/240V 50/60Hz |
| Operating Temperature | -20° to 45°C |
| Power Consumption | 150W/sqm (average), 450W/sqm (max) |
| Lifespan | 100.000 hrs |
